Self-propelled wood chipper on tracks for rough terrain.

The GTS1300R wood chipper is equipped with caterpillar tracks to operate on rough and hard to access terrain. Therefore, this machine is not only suitable for garden and park, but also for forestry. The construction can easily manage steep hills up to 20°. The chassis is specially lowered, making the input height only 10 cm higher than the GTS1300 on wheels.

The GTS1300R is a powerful wood chipper with compact dimensions. Therefore, the machine fits in a mini-van, on each trailer and even through a standard garden gate.

The shredding system consists of a metal drum (rotor) on which 2 blades are mounted. This works fast, efficient and has a high capacity. The system pulls in fresh wood with a diameter of up to 10 cm (dry wood up to ¥ 8 cm), after which this is effortlessly shredded into fine wood chips.

The wood chips are ejected high and are discharged straight into a trailer or wheel barrow via the turnable output chute with adjustable deflector. The wood chipper comes standard with PRO blades, that last twice as long as regular blades.

The GTS1300R is certified by TÜV Rheinland and meets the highest safety standards.

TECHNICAL SPECIFICATIONS

– Engine: Loncin G420FD e-start

– Power: 15 hp / 11.02 kW

– Displacement: 420 cc

– Tank capacity: 6.5 l

– Fuel: Euro98 (E5)

– Max. diameter wood: 10 cm

– Input: 50 x 28 cm

– Input height: 111 cm

– Output height: 160 cm

– Deflector possible to adjust continuously to 85°

– Turnable output

– Panic bar and safety switches

– 2 PRO blades + 1 counter blade

– Dimensions: 215 x 72 x 160 cm

– Weight: 362 kg

Chassis

– Loncin G200F (5.5 hp)

– Number of gears: 3 x forward and 1 x reverse

– Max. speed: 4.5 km/h

– Width of tracks: 18 cm
